Vision X BMW070560 Blacktips 35W 5 LED Marine Worklight
Blacktips Marine LED Work Light Series Is Developed and Constructed to Withstand the Rough Conditions on Board
Blacktips Marine LED work light series is developed and constructed to withstand the rough conditions on board. The latest Cree LEDs are used in a robust light housing and thanks to the CISPR 25: rating radio interference is prevented and other electronic components are unaffected. Screened off inside electronics prevents external corrosion.
Highest IP-rating ā IP-69k (submersible down to 3 meters), 3m marine-graded power cable incl. deutsch connector.
The Blacktips Marine LED work light series offers outstanding light output in a functional design utilizing a forward rake trunnion bracket, with integrated aiming markings on the sides and base of the bracket. Utilizing the aiming system in conjunction with 3d fit outs to ensure the correct light for any needs. Capable of standing up to 60G rms of intense vibrations in the harshest conditions, these lights are the perfect solution for replacing unreliable lights on your ship. Thereās something comforting about being able to install a light and never have to worry about it.
Rugged and Durable Construction
The combination of a die-cast 6061 aluminum housing, marine grade anti-corrosive coating, unbreakable polycarbonate lens, integrated deutsch connector, reinforced gasketed bezel and a strengthened trunnion bracket create a one of a kind, high-powered light that will outshine and outlast the competition.
Prime Drive Technology
Prime Drive Technology from Vision X Lighting controls vital functions such as temperature control and dimming on your lights. This advanced technology can increase or decrease the intervals at which the LEDs turn on and off in order to lower the bars overall temperature and maximize the lifespan.
Features:
- Rugged and Durable Construction
- Prime Drive Technology
Specifications:
- LEDs: 5 x 7W Cree
- Light Colour Temp: 6000K
- Effective Lumens: 3305
- Raw Lumens: 4000
- Voltage: 11-65V
- Current Draw: 2.9A @12V
- Wattage: 35W
- Connector: Deutsch DT04-2P
- Bracket Type: Forward rake trunnion bracket with aiming system
- Weight: 1.00kg
- Width: 123mm
- Height: 112mm
- Depth: 101mm
- IP Rating: IP69K
- Vibration Dampened & Shock Proof: 60 Grms
- EMC Approval: CISPR25 Klass 1/CE approved
- Lens Material: Polycarbonate
- Housing Material: Die-cast 6061 aluminum
- Housing Coating: Marine Grade Anti-Corrosive
- Light Patterns: 60Ā° Euro (Also available in 10Ā°, 25Ā°, 40Ā°)
